Y5V capacitor is a general-purpose capacitor with certain temperature limits, and its capacity can vary from 22% to - 82% in the range of - 30 ℃ to 85 ℃.

The high dielectric constant of Y5V allows for manufacturing up to 4.7 in a smaller physical size μ F capacitor.

The value range of Y5V capacitor is shown in the following table

Package DC=25V DC=50V

0805 0.01 μ F---0.39 μ F 0.01 μ F---0.1 μ F

1206 0.01 μ F---1 μ F 0.01 μ F---0.33 μ F

1210 0.1 μ F---1.5 μ F 0.01 μ F---0.47 μ F

2225 0.68 μ F---2.2 μ F 0.68 μ F---1.5 μ F

Other technical indicators of Y5V capacitor are as follows:

Operating temperature range - 30 ℃ - 85 ℃

Temperature characteristic 22% - 82%

Maximum dielectric loss 5%

The naming method for chip capacitors can be found on the AVX website. Different company naming methods may vary slightly.
